Stabilus 5B-047362 lift support for the 2005-2013 Chevrolet Corvette convertible top. 10.47 in extended length, 48 lbs of force, a 13 mm ball socket long cup (steel) type (1/2 in) body end and a 10 mm ball socket (3/8 in) shaft end, and 6.95 in compressed length. Replaces the original support to bring a sagging or slow-closing convertible top back to proper lift and hold. Fitment note: Stowage Compartment -Manual Top Only-. Sold one per unit; replacing the pair keeps lift force even. Stroke is 3.52 in. Includes a 1-year warranty.
- SKU: 5B-047362-W
- A Interchanges: 047362, 10376352, 5B047362, 5B-047362, 5B047362W, 5B-047362-W, 6456UA, SG430108
- BC Body Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/rd222m6x100.gif
- BC Shaft Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/rd222m6x100.gif
- Body Connection: Ball Socket Long Cup (Steel) Type=13mm=1/2"=.50"
- Compressed Length B [in]: 6.95
- Custom Qty: 2
- End Fitting Size: 13MM
- End Fitting Type: Ball Socket
- Extended Length A [in]: 10.47
- Finish: Black
- Force (Lbs): 48
- Force Newtons: 214
- Include In Length Search: No
- Include In mmty Search: No
- MSDS Info: Click Here to Download Stabilus MSDS Sheet.
- Manufacturer: Stabilus
- Manufacturer Logo: portal.liftsupportsdepot.com/images/nextopia/stabiluswhitesmallb.gif
- Name (Fitment): Made by Stabilus Fits the Convertible Top | 5B-047362
- Quantity Sold As: Each
- Ref Code: -2
- Shaft Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Stroke C [in]: 3.52
- UPC: 840265740507
- Vehicle Location: Convertible Top
2 Reviews Hide Reviews Show Reviews
-
OEM struts for C6 Corvette
I found OEM replacement struts for my C6 Corvette convertible at a great price with excellent customer service and quick delivery.
-
2006 Corvette Trunk Lid
these fit perfect.....the ones I ordered from another place Did Not...…..thanks
Stabilus warrants products to be free from defects in materials or workmanship for a period of 1-year.
