Stabilus 4B-168658 lift support for the 2004-2011 Chevrolet Aveo hatch. 15.35 in extended length, 92 lbs of force, 10 mm ball socket (3/8 in) end fittings, and 9.59 in compressed length. Direct-fit replacement that restores full lift and hold to a hatch that has started to sag or drift down. Also fits the 2004-2011 Chevrolet AVEO5 and 2009-2010 Pontiac G3. Sold individually. Most applications use two, so replace both together. Cross-references 015685, 168658, 4B168658W, 96540939, 998305, SG430092, SG330097. Covered by a 1-year warranty.
- SKU: 4B-168658-W
- A Interchanges: 015685, 168658, 4B168658, 4B-168658, 4B168658W, 4B-168658-W, 96540939, 998305, SG430092, SG330097
- BC Body Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/ballsocketnylon10mm383916deg.gif
- BC Shaft Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/ballsocketnylon10mm383916deg.gif
- Body Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39" 16 Deg Angle
- Compressed Length B [in]: 9.59
- Custom Qty: 2
- End Fitting Size: 10MM
- End Fitting Type: Ball Socket
- Extended Length A [in]: 15.35
- Finish: Black
- Force (Lbs): 92
- Force Newtons: 409
- Include In Length Search: No
- Include In mmty Search: No
- MSDS Info: Click Here to Download Stabilus MSDS Sheet.
- Manufacturer: Stabilus
- Manufacturer Logo: portal.liftsupportsdepot.com/images/nextopia/stabiluswhitesmallb.gif
- Name (Fitment): Made by Stabilus Fits the Hatch | 4B-168658
- Quantity Sold As: Each
- Ref Code: 2
- Shaft Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Stroke C [in]: 5.77
- UPC: 840265744949
- Vehicle Location: Hatch
There are no reviews yet.
Write a Review
Stabilus warrants products to be free from defects in materials or workmanship for a period of 1-year.
