Lift Supports Depot PM3516 lift support for the 2006-2011 Suzuki SX4 hatch. 17.32 in extended length, 94 lbs of force, 10 mm ball socket (3/8 in) end fittings, and 10.71 in compressed length. Replaces the original support to bring a sagging or slow-closing hatch back to proper lift and hold. Fitment note: Supplied Without Bracket (Must Reuse). Sold one per unit; replacing the pair keeps lift force even. Stroke is 6.61 in. The rod measures 8 mm and the cylinder 18 mm. Finished in black. Includes a 1-year warranty.
- SKU: PM3516-W
- A Interchanges: 4756UW, 8185079J00, 81850-79J00, 8186079J00, 81860-79J00, 8186079J01, 81860-79J01, PM3516
- BC Body Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/pc1249-2.gif
- BC Shaft Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/pc1249-2.gif
- Body Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Compressed Length B [in]: 10.71
- Custom Qty: 2
- Cylinder Diameter (MM): 18
- End Fitting Size: 10MM
- End Fitting Type: Ball Socket
- Extended Length A [in]: 17.32
- Finish: Black
- Force (Lbs): 94
- Force Newtons: 418
- Include In Length Search: No
- Include In mmty Search: Yes
- MSDS Info: Click Here to Download the Lift Supports Depot MSDS Sheet.
- Manufacturer: Lift Supports Depot
- Manufacturer Logo: portal.liftsupportsdepot.com/images/nextopia/liftsupportlogosmall.gif
- Name (Fitment): Made by Lift Supports Depot Fits the Hatch | PM3516
- Quantity Sold As: Each
- Ref Code: 0
- Rod Diameter (MM): 8
- Shaft Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Stroke C [in]: 6.61
- Vehicle Location: Hatch
