Stabilus SG230059A gas-charged lift support with 21.65 in extended length, 19 lbs of force, 10 mm ball socket (3/8 in) end fittings, and 13.66 in compressed length. Replaces 15162860, 4247QU, 8196341, 9899VN, SG230059. Stroke is 7.99 in. The rod measures 6 mm and the cylinder 15 mm. Finished in black. Covered by a 1-year warranty.
- SKU: SG230059A-W
- A Interchanges: 15162860, 4247QU, 8196341, 9899VN, SG230059, SG230059A, SG230059A
- BC Body Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/pc1249-2.gif
- BC Shaft Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/pc1249-2.gif
- Body Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Compressed Length B [in]: 13.66
- Custom Qty: 2
- Cylinder Diameter (MM): 15
- End Fitting Size: 10MM
- End Fitting Type: Ball Socket
- Extended Length A [in]: 21.65
- Finish: Black
- Force (Lbs): 19
- Force Newtons: 85
- Include In Length Search: No
- Include In mmty Search: No
- Manufacturer: Stabilus
- Manufacturer Logo: portal.liftsupportsdepot.com/images/nextopia/stabiluswhitesmallb.gif
- Name (Fitment): Made by Stabilus Fits the Front & Center Side Panel | sg230059A
- Quantity Sold As: Each
- Ref Code: 0
- Rod Diameter (MM): 6
- Shaft Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Stroke C [in]: 7.99
- UPC: 708609187695
- Vehicle Location: Front & Center Side Panel
