Strong Arm 6120 lift support for the 2007-2014 Ford Edge liftgate. 22.06 in extended length, 144 lbs of force, 10 mm ball socket (3/8 in) end fittings, and 14.31 in compressed length. Replaces the original support to bring a sagging or slow-closing liftgate back to proper lift and hold. Sold one per unit; replacing the pair keeps lift force even. Stroke is 7.75 in. The rod measures 10 mm and the cylinder 22 mm. Finished in black. Includes a 1-year warranty.
- SKU: 6120-W
- A Interchanges: 95485, 237330, 237569, 6120, 7T4Z 78406A10A, 7T4Z 78406A10-A, 7T4Z 78406A11A, 7T4Z 78406A11-A, 7T4Z78406A10A, 7T4Z78406A11A, C95485, SG304084
- BC Body Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/ballsocketnylon10mm383916deg.gif
- BC Shaft Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/ballsocketnylon10mm383916deg.gif
- Body Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39" 16 Deg Angle
- Compressed Length B [in]: 14.31
- Custom Qty: 2
- Cylinder Diameter (MM): 22
- End Fitting Size: 10MM
- End Fitting Type: Ball Socket
- Extended Length A [in]: 22.06
- Finish: Black
- Force (Lbs): 144
- Force Newtons: 641
- Include In Length Search: No
- Include In mmty Search: No
- Manufacturer: Strong Arm
- Manufacturer Logo: portal.liftsupportsdepot.com/images/nextopia/strongarmlogosmall.gif
- Name (Fitment): Made by Strong Arm Fits the Liftgate | 6120
- Quantity Sold As: Each
- Ref Code: 4
- Rod Diameter (MM): 10
- Shaft Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Stroke C [in]: 7.75
- UPC: 845998006654
- Vehicle Location: Liftgate
1 Review Hide Reviews Show Reviews
-
Lift and Separate
Easy to install. High quality product and design. Immediately solved the head banging problem.
When used in accordance with the StrongArm Vehicle Application Listing, AVM warrants the StrongArm Gas Charged Lift Support against any defects in manufacturing or workmanship for a period of 12 months from installation.
