Strong Arm 6260 lift support for the 2008-2012 Ford Escape rear glass window. 17.42 in extended length, 33 lbs of force, a 10 mm ball socket (3/8 in) body end and a 8 mm ball socket (5/16 in) shaft end, and 11.17 in compressed length. Direct-fit replacement for the original support, restoring proper lift and hold on a sagging or failing rear glass window. Also fits the 2008-2011 Mercury Mariner and 2008-2012 Ford-Mexico Escape. Sold individually; replacing both sides is recommended. Stroke is 6.25 in. Backed by a 1-year warranty.
- SKU: 6260-W
- A Interchanges: 96260, 6260, 631923, 632162, 8L847842105AD, D96260, SG304099
- BC Body Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/pc1249-2.gif
- BC Shaft Connector End Fitting Type TN: portal.liftsupportsdepot.com/images/endfitting/pc1249-2.gif
- Body Connection: Ball Socket U Band (Nylon)=10mm=3/8"=.39"
- Compressed Length B [in]: 11.17
- Custom Qty: 2
- Cylinder Diameter (MM): 15
- End Fitting Size: 10MM
- End Fitting Type: Ball Socket
- Extended Length A [in]: 17.42
- Finish: Black
- Force (Lbs): 33
- Force Newtons: 147
- Include In Length Search: No
- Include In mmty Search: No
- Manufacturer: Strong Arm
- Manufacturer Logo: portal.liftsupportsdepot.com/images/nextopia/strongarmlogosmall.gif
- Name (Fitment): Made by Strong Arm Fits the Rear Glass Window | 6260
- Quantity Sold As: Each
- Ref Code: 10
- Rod Diameter (MM): 6
- Shaft Connection: Ball Socket U Band (Nylon)=8mm=5/16"=.32"
- Stroke C [in]: 6.25
- UPC: 845998010538
- Vehicle Location: Rear Glass Window
1 Review Hide Reviews Show Reviews
-
The best
I purchased new life supports for my Escape, they work just as it did when the car was brand new. Thank you
When used in accordance with the StrongArm Vehicle Application Listing, AVM warrants the StrongArm Gas Charged Lift Support against any defects in manufacturing or workmanship for a period of 12 months from installation.
